JUNG Hebe- und Transporttechnik GmbH
Steerable trolley JLB 40 H Professional
Power and stability - the JLB 40 H transport trolley from JUNG can lift loads of up to 40 t with an installation height of 230 mm.
Load capacity: 40 t (in a set 80 t*)
Height: 230 mm
Transport trolleys series H professional
*) Set consisting of JLB 40 H + JFB 40 H
Height: 230 mm
Transport trolleys series H professional
*) Set consisting of JLB 40 H + JFB 40 H
Product number:
09 400 206-H
Weight:
314 kg
Product information "Steerable trolley JLB 40 H Professional"
Advantages of the transport trolleys JLB 40 H
- Unrivalled: Small and lightweight trolleys at super high capacity.
- Steerable transport trolleys with pivoting cassettes for a better load distribution at all castors and the floor.
- All transport trolleys are ready for use.
- The steerable transport trolley is fitted with a ball bearing supported turntable and a handlebar.
- Also available as Professional version with JUWAthan twin castors: the double castor design results in dramatically easier steering due to reduced friction forces in curves.
| Castor dimensions (Ø x l mm): | 200 x 85 |
|---|---|
| Dimensions steerable (mm): | 650 x 1 060 |
| Handlebar with pulling eye (mm): | 1 600 |
| Height (mm): | 230 |
| Load capacity (suitable): | 41 - 80 t |
| Load capacity (t): | 40 |
| Number of twin castors (pcs.): | 16 |
| Supporting surface of turnable Ø (mm): | 250 |
| Weight JUWAthan® (kg): | 314 |
