JUNG Hebe- und Transporttechnik GmbH

Steerable trolley JLB 7 K Professional

High-performance transport trolley from JUNG. The JLB 7 K professional steerable trolley transports loads up to 7 t with an installation height of 110 mm.

Load capacity: 7 t (im Set 14 t*)
Height: 110 mm

Transport trolley series K professional

*)Set consisting of JLB 7 K + JFB 7 K

Price on request

Prices incl. VAT plus shipping costs

Available

Request an offer

PDF-Datasheet

Product number: 07 071 085-D

Weight: 35 kg

Product information "Steerable trolley JLB 7 K Professional"

Advantages of the transport trolley JLB 7 K Professional

The double roller design results in dramatically easier steering due to reduced friction forces in castors. The much lower friction resistance also causes the trolleys on the rear axis to follow in a truer course.
You need 30 % less power for steering.
Higher capacity with professional castors, at same dimension as series K trolleys.
All transport trolleys are ready for use: the steerable transport trolley is fitted with a ball bearing supported turntable and a handlebar.
The series K handlebars are now also available with a removable handle, which is also available as a re-fitting set.
Non-marking support wheels.
Inspected according to technical regulation ANSI ⁄ ASME (USA)

Castor dimensions (Ø x l mm):	85 x 85
Dimensions steerable (mm):	445 x 590
Handlebar with pulling eye (mm):	1 210
Height (mm):	110
Load capacity (suitable):	11 - 15 t
Load capacity (t):	7
Number of twin castors (pcs.):	8
Supporting surface of turnable Ø (mm):	150
Weight Professional (kg):	35
