JUNG Hebe- und Transporttechnik GmbH
Steerable trolley JLB 15 G
High payloads and compact design - the JLB 15 G steering unit transports loads up to 15 t with an installation height of 180 mm.
Load capacity: 15 t (in a set 30 t*)
Height: 180 mm
*) Set consisting of JLB 15 G + JFB 15 G
Height: 180 mm
*) Set consisting of JLB 15 G + JFB 15 G
Product number:
09 153 140-V
Weight:
92 kg
Product information "Steerable trolley JLB 15 G"
Advantages of the transport trolley JLB 15 G
- The double castor design results in dramatically easier steering due to reduced friction forces in curves.
- All transport trolleys are ready for use.
- The steerable transport trolley is fitted with a ball bearing supported turntable and a handlebar.
| Bauart: | Lenkwerk |
|---|---|
| Castor dimensions (Ø x l mm): | 140 x 59 |
| Dimensions steerable (mm): | 565 x 610 |
| Handlebar with pulling eye (mm): | 1 230 |
| Height (mm): | 180 |
| Load capacity (suitable): | 26 - 30 t |
| Load capacity (t): | 15 |
| Number of castors (Pieces): | 12 |
| Supporting surface of turnable Ø (mm): | 215 |
