JUNG Hebe- und Transporttechnik GmbH
JH 6 G plus - Hydraulic jack
High-quality jack from JUNG. The hydraulic lifting device JH 6 G plus lifts a load of 6 t and reaches a maximum lifting height of 140 mm.
with integrated pump unit
Load capacity: 6 t
Stroke: 140 mm
Load capacity: 6 t
Stroke: 140 mm
Product number:
01 060 102-G
Weight:
22 kg
Product information "JH 6 G plus - Hydraulic jack "
Advantages of the hydraulic jack JH 6 G plus
- Slide shoe design inside the guiding track prevents twisting of the piston inside the lifting cylinder. This guarantees better force distribution, less friction and reduced wear compared to conventional jacks.
- Reduced maintenance costs due to easy change slide shoes and removable pump unit.
- Extremely lightweight with high performance due to the use of highquality material and innovative design.
- Continuous adjustment to the load due to swiveling safety toe. Secure stableness in every situation even in lifted position.
- JH 15 / JH 20 G plus serial outfitted with fast stroke.
- Die-forged steel toe provides impact resistance.
| Cylinder volume (l): | 0,18 |
|---|---|
| Height (mm): | 280 |
| Length feet in front (mm): | 326 |
| Length feet on side (mm): | 311 |
| Lift toe adjustment: | 6 x 29 |
| Load capacity on top plate (t): | 6 |
| Maximum lift toe height (mm): | 157 |
| Minimum lift toe height (mm): | 12 |
| Pump unit included: | Ja |
| Stroke (mm): | 140 |
| Toe depth (mm): | 50 |
| Toe width front (mm): | 50 |
| Top plate height (mm): | 245 |
| Width (mm): | 233 |
