Transport trolley JLA-e 25/50 H facelift - Set

The electric-powered transport trolley set JLA-e 25/50 H is easy to operate and does not require an additional towing vehicle. Suitable for loads up to 50 tons.

Load capacity: in a set 50 t*
Height: 230 mm
*) Set consisting of JLA-e 25/50 H + JFB 25 G (adjusted height)

Electric-powered transport trolleys

Price on request

Prices incl. VAT plus shipping costs

Available

Request an offer

PDF-Datasheet

Product number: 22 025 220-H set

Weight: 399 kg

Product information "Transport trolley JLA-e 25/50 H facelift - Set "

Included items of the electric-powered transport trolley setJLA-e 25/50 H facelift

1 x Electric-powered transport trolleyJLA-e 25/50 H facelift
1 x High performance accumulator with pulse charging device
1 x Remote control with battery (the remote control can be switched from two-handed to one-handed operation - flexible left/right), charger and belt holder
Adequate moving skates - 1 x JFB 25 G (with height 230 mm)
Load capacity JLA-e: 25 t / Load capacity trolley: 25 t
Inspected according to technical regulation DGUV V68 (German)

Cassette dimensions (mm):	460 x 330
Height (mm):	230
JLA-e:	1x JLA-e 25/50 H
Load capacity transport trolley (kg):	2 x 12 500
Number of castors transport trolley (kg):	20
Supporting surface cassette (mm):	220 x 120
Transport trolley:	1 x JFB 25 G (angepasste Einbauhöhe)
