JUNG Hebe- und Transporttechnik GmbH
Container trolley JTL 20 G Twistlock
For transporting containers - the tandem trolleys JTL 20 G TL with twistlock for loads up to 20 t.
Load capacity: 20 t (in a set 40 t*)
Height: 215 mm
ISO-length: 2260 mm
*) Set consisting of JTL 20 G TL + JFB 20 G TL
Height: 215 mm
ISO-length: 2260 mm
*) Set consisting of JTL 20 G TL + JFB 20 G TL
Product number:
12 202 140-TL
Weight:
168 kg
Product information "Container trolley JTL 20 G Twistlock"
Advantages of the tandem trolleys JTL 20 G TL with Twistlock
- Safe transport of containers.
- Low height for moving containers low to the ground.
- Lock-to-hold mechanism between the trolley and the containers (Twistlock).
- Compatible with all ISO-containers.
- “Twistlock” version for outdoor transport for use on pavement includes turntables fitted with “Twistlock” to secure containers to transport trolleys. Including 2-parts connecting bars fixed length 2.26 m / 89 inch and pulling handle with towing eye.
| Castor dimensions (Ø x l mm): | 140 x 59 |
|---|---|
| Dimensions steerable (mm): | 1 260 x 2 700 |
| Handlebar with pulling eye (mm): | 1 230 |
| Height (mm): | 215 |
| ISO-length (mm): | 2 260 |
| Load capacity (t): | 20 |
| Number of castors (Pieces): | 16 |
| Supporting surface of turnable Ø (mm): | 170 |
| Total height (mm): | 300 |
| Weight JUWAthan®plus (kg): | 168 |
