Transport trolley JLA-p Set 2
The JLA-p 15/30 G transport trolley set enables easy control, compact transport, and no battery charging time. Suitable for loads up to 30 tons.
Air-powered transport trolley
Load capacity: 15 t
Height: 180 mm
*)Set consisting of JLA-p 15/30, supply hose and hose cart
Load capacity: 15 t
Height: 180 mm
*)Set consisting of JLA-p 15/30, supply hose and hose cart
Product number:
22 150 140-VP2
Weight:
250 kg
Product information "Transport trolley JLA-p Set 2"
Included items of the JLA-p 15/30 G air-powered transport trolley sets
- JLA-p 15 ⁄ 30 G includes control unit
- Hose cart complete with hose reel
- 30 m [98 ft] air supply hose with Ø 19 mm [3/4 inch]
- 1 Liter oil [1 quart] for pneumatic motors
- 400 ml [13 oz.] chain spray
- Inspected according to technical regulation DGUV V68 (German)
| Air consumption (L/sec): | 25 |
|---|---|
| Cart + oil + chain spray: | 1 x |
| Castor dimensions (Ø x l mm): | 140 x 59 |
| Dimensions (mm): | 650 x 1 000 |
| Height (mm): | 180 |
| Hose length / diameter: | 30 m/19 mm |
| JLA-p incl. control box: | 1 x |
| Load capacity (t): | 15 |
| Number of castors (Pieces): | 16 |
| Pulling capacity (t): | 30 |
| Required air pressure (bar): | 8 |
| Supporting surface of turnable Ø (mm): | 215 |
| Weight without control box (kg): | 175 |
