JUNG Hebe- und Transporttechnik GmbH
Steerable trolley JL 12 K
High-performance transport trolley from JUNG. The JL 12 K steerable trolley transports loads up to 12 t with an installation height of 110 mm.
Load capacity: 12 t (in a set 24 t*)
Height: 110 mm
*)Set consisting of JLB 12 K + JFB 12 K
Height: 110 mm
*)Set consisting of JLB 12 K + JFB 12 K
Product number:
07 120 085-V
Weight:
62 kg
Product information "Steerable trolley JL 12 K"
Advantages of the transport trolley JL 12 K
- The trolleys are equipped with highest quality castors as standard.
- The innovative housing design of the transport system ensures an optimal balance between performance and weight.
- All transport trolleys are ready for use: the steerable transport trolley is fitted with a ball bearing supported turntable and a handlebar.
- Non-marking support wheels.
- The transport system is comprised of two cassettes with a connecting rod. An extended connecting rod is available upon request.
- Inspected according to technical regulation ANSI ⁄ ASME (USA)
| Castor dimensions (Ø x l mm): | 85 x 85 |
|---|---|
| Dimensions steerable (mm): | 580 x 1 000 |
| Handlebar with pulling eye (mm): | 1 210 |
| Height (mm): | 110 |
| Load capacity (suitable): | 21 - 25 t |
| Load capacity (t): | 12 |
| Number of castors (Pieces): | 16 |
| Supporting surface of turnable Ø (mm): | 170 |
| Weight JUWAthan®plus (kg): | 64 |
