JPE 30 NVR - Electrical pump
Working pressure: 520 bar
Product information "JPE 30 NVR - Electrical pump"
- Quick connectors with drip free rapid closure valves.
- One oil circuit is capable of supplying two hydraulic jacks.
- Easy handling.
- Maximum safety during operation due to cable remote control.
- Sturdy two stage electric pumps available in different versions.
- Easily controllable: JPE 30-NVR with precision lowering regulator.
- Includes transport cart for easy and safe transport.
| Connections (pcs.): | 2 |
|---|---|
| Dimensions L x W x H (mm): | 680 x 330 x 600 |
| Flow rate high pressure (L/min): | 0,33 - 520 bar |
| Flow rate low pressure (L/min): | 3,9 - 7 bar |
| Maximum working pressure (bar): | 520 |
| Motor facts: | 230 V, 50 Hz, 5 A |
| Oil volume complete/usable (L): | 7,6/4,8 |
| Usable jacks: | Alle Hebegeräte |
| Weight with oil and cart (kg): | 38 |
